Product Details:
|
| Raw Material: | Mgo/mgcl2/sawdust | Warranty: | 1 Year |
|---|---|---|---|
| Production Capacity: | 1300 Sheets | Certification: | CE |
| Weight: | 20T | Dimension: | 25m*1.58m*1.78m |
| Panel Width: | 1300mm | ||
| Highlight: | Construction Material Making Machinery,polyurethane sandwich panel machine |
||
Insulated Sandwich Panels Mgo Board Equipment for Building Mould Board Production Line
1. Product features
The product manufactured by this equipment has following features:fireproof ,waterproof,environment protection and no toxicity .at the same time it is resistant against acid,alkali and aging. This product can be nailed,planed ,sawed and sticked.in the view of that its fireproofing grade is A .so our product will not be combustible when the fire is 800-1000C.at the same time when our product is fell to the water for a week ,there are not the following phenomenon such as chalking,deformation and warp.in light of there is not glue in the raw materials.so there is not formaldhyde and benzenz for our boards .
2. The production line mainly produce all kinds of magnesium oxide boards ,they can be used for ceiling,wall skirting ,decorating of wall indoor and lining board for furniture .As follow:
1) simulated wooden board :After national grade testing ,its appearance is the same as that of the wooden board ,and its decorating effect, performance and performance-to-price atio are all better than the same board .with a large breadth ,it not only has the features which the wooden board owns ,such as nailed ,sawed ,planed and stuck,but also don’t need painting ,so it is green environment-friendly. For example : simulation beech board red(black) walaut board and bubinga(canthor).
2) Fireproof embossed door:after province-level detection ,it has such features:fireproof ,water-proof ,sound insulation ,heat preservation,variety and low cost.
3) Wall decorating mural painting:The board produced by the board-making machine can be made into various decorating art mural painting about landscape, flower-and-bird,insect-and-fish as well as character.the product gets popularity from customers with excellent quality and reasonable price
4) Vent-pipe :The polystylrene sandwich panle produced by this machine can be made into the vent-pipe used by the central air-conditioning system and all kinds of ventilation facility ,and the product is fireproof ,damp-proof,antiseptic,light-weight,heat-preservation ,long-performance life and low-price.In view of the above features,it wins much favor from users.
5) Building mould board :The strengthened mould plate with this technology can replace steel mould board ,bamboo&wood mould board and multiayer board .Being a high-profit product ,this board is applied widely in all kinds of concrete engineering with low-cost,high strength,long life and convenient to use .the board is high-profit product
In addition , in view of unique effect and great profit,various embossed board with decorative pattern and glazd pantile can replace carved wall board of wallpaper
1 |
Air-dry density | ≤ (Standard index)50kg/m2 | (Test Value) 30.0kg/ m2 |
| 2 | Drying shrinkage rate of the board | ≤0.08% | 0.015% |
| 3 | Anti-breaking load | ≥1400N | 5640N |
| 4 | Anti-impact | No breakage phenomenon such as cracking after three impacts | No breakage phenomenon such as cracking after three impacts |
| 5 | Thermal resistance of main section (T=90mm) | ≥1.35(m2.k)/w | ≥1.36(m2.k)/w |
| 6 | Thermal bridges area ratio | ≤8% | 2.22% |
| 7 | Sound reduction Index | 36dB | |
| 8 | Radioactivity | None |
3. Unique advantage
1) after installation and commissioning, we will provide mgo board formula suitable with client’s demand ,ensuring clients can producce qualified mgo board .additional,we will help local experienced engineer to master the production process.
2)The company regards product quality as the lives of enterprise,the main components and wearing parts are made of high quality wear-resistant materials and advanced processing technology,so that the equipment endurable and wear resisting ,wearing parts warranty for one year.
