Product Details:
|
| Raw Material: | Mgo/mgcl2/sawdust | Warranty: | 1 Year |
|---|---|---|---|
| Texture Of Material: | Steel | Type: | Free Standing |
| Standard: | CE | Use: | Making Board |
| Main Process: | Forming | Feature: | Long Life |
| Highlight: | Construction Material Making Machinery,polyurethane sandwich panel machine |
||
Steel Structure Machines for Construction Industries Glass Magnesium Oxide Board Line
1.product
This mgo board production machine can used to produce MGO door board, MGO board, Sanding mgo board,paper laminated mgo board.
It is the multi- functional production line for many kinds of modern construction materials, is well received by clients who focus on green environment-friendly buildings and energy-saving constructions.
2. Application of Board:
The board produced by our machine can be used for ceiling, wall skirting, decorating of indoor wall and lining board for furniture.
And our board can replace three-ply board, five-ply board, flakeboard, MDF (Medium Density Fiberboard ) and Gypsum Board.
3. Board performance:
A. Oxygenic index%: >90
B. Level combustion: SO
C. Vertical combustion: SO
D. Water content rate: 10.9%
E. Capacity: 1.15g/cm3
F. Static bending intensity: 169.46Mpa
G. Density: T/ m3 1.13
H. Water resistance: Without chalking for 24 hours and there is no change on surface
I. No “Three-wastes” (waste water, waste gas and waste residue), no pollution and environmental protection
4.Production conditions
The production line for mgo board is composed of board-making machine,glue-spreading and veneering-drying machine and glazing machine.according to the production and the automatic degree, this production line is divided into 6 models and three specifications ,such as large ,middle and small specification.The production line for mgo board has :production workshop ,finished product workshop and raw material warehouse . workshop:100---1000m2,worker:3---6person,water:ordinary water,electricity:1.1—10KW(according to different scale)
1 |
Air-dry density | ≤ (Standard index)50kg/m2 | (Test Value) 30.0kg/ m2 |
| 2 | Drying shrinkage rate of the board | ≤0.08% | 0.015% |
| 3 | Anti-breaking load | ≥1400N | 5640N |
| 4 | Anti-impact | No breakage phenomenon such as cracking after three impacts | No breakage phenomenon such as cracking after three impacts |
| 5 | Thermal resistance of main section (T=90mm) | ≥1.35(m2.k)/w | ≥1.36(m2.k)/w |
| 6 | Thermal bridges area ratio | ≤8% | 2.22% |
| 7 | Sound reduction Index | 36dB | |
| 8 | Radioactivity | None |
5. Excellect service
1)Fully life-cycle value services
Our company provides mgo board production line design ,cost accounting,installation and operation,equipment maintenance and the whole life cycle techincal support
2)all-around thechnical service
We provide technical formula for clients,to help clients to occupy the leading position in the market.
3)complete data specification
Provide production line equipment technical data and instructions,and provide the mgo board production line formula.
4)quality commitment
The company regards product quality as the lives of enterprise,the main components and wearing parts are made of high quality wear-resistant materials and advanced processing technology,so that the equipment endurable and wear resisting ,wearing parts warranty for one year.
